1/4 x 28 SAE Self-forming Thread Straight Hydraulic Grease Fitting – 10 pcs
£3.10
205530
In stock
Looking to order large quantities of this product? Contact us today for a quote.
1/4 x 28 SAE Self-forming Thread Straight Hydraulic Grease Fitting. Self-forming threads can be screwed or driven into an untapped hole. The recommended size of the hole for a 1/4 x 28 thread is 5.84-5.97mm (Ref SAE J534) but can be dependent on the material.
Avoid chamfering as a sharp edge to the hole helps the thread bite.
| Weight | 14 kg |
|---|---|
| Angle | Straight |
| Ball_check | Yes |
| Diagram | Fig.1 |
| Dims_a_i | 0.56 |
| Dims_a_m | 14.2 |
| Dims_b_i | 0.21 |
| Dims_b_m | 5.3 |
| Dims_c_i | N/A |
| Dims_c_m | N/A |
| Hardened | Yes |
| Hidden | No |
| Hole | ref. SAE J534 |
| International | SAE J534 |
| Manufacturer | Hydraulic Grease Nipple |
| Material | Mild Steel |
| Product_long | Normal |
| Spanner_wrench_size | 5/16" Hexagon |
| Stock_item | Class 2 Parts |
| Thread | 1/4 x 28 Special Taper |
| Thread_type | Self-forming |
| Zinc_plating | Yes |
